MT-L12D-18Y

IP camera module

Anjoy Vision

5MP 18× network dual-light camera module

1/2.8-inch 5MP CMOS sensor;
H.265+, H.265, H.264 encoding
Supports software light sensing: dual-light mode, full-colour mode, IR mode
Uses dual-light illumination,
18× optical zoom supported
One-touch watch, one-touch patrol, one-touch tracking
Supports smart analysis: accurate human detection, area detection, tripwire detection
Supports two-way audio, voice announcements, custom voice
Supports image flip, supports digital WDR
Onvif, P2P supported;

Specifications
Model	MT-L12D-18Y
Lens focal length	5.3±5%~96±5%mm
Maximum zoom ratio	18X
Lens iris	F1.8~F3.9
Horizontal range	Horizontal: 355°, vertical: -15~90°
Number of presets	255
Control speed	Horizontal 120°/s, vertical 60°/s
Supported functions	Human tracking, preset patrol, area patrol, defog
Power-off position memory	Supported
Illuminator	IR 700mA per group (2 groups), white light 500mA per group (1 group)
SoC	SSC37X
Image sensor	5MP, 1/2.8" CMOS
Video processing	H.265+/H.265/H.264 video encoding; bitrate adjustable 0.1M~1.5Mbps; frame rate adjustable 1~25 fps;
Image output	Main stream: 25FPS@(2592×1944, 2560×1440, 2304×1296, 1920×1080, 1280×720); sub stream: 640×360,480x360,CIF;
TF interface	1 × TF storage slot, up to 512G;
Audio interface	Audio: 1 ch line input, 1 ch output
Audio processing	G.711 encoding; two-way voice intercom; audio-video synchronisation;
Network interface	1 × RJ45 Ethernet interface, 10/100M auto-negotiating;
Reliability	Full lightning protection for power and network, compliant with national standard GB/T17626.5 and international standard IEC61000-4-5
Functions	OSD, real-time audio and video transmission, precise human detection, dual-light alarm, sound alarm;
Network protocols	Supports TCP/TP, IPv4, DHCP, RTSP, P2P
Mobile monitoring	Mobile monitoring (iOS, Android); supports AC18Pro
Power supply	DC12V power input
Operating conditions	-40~+65℃
