MY-F31H-4G

4G camera module

Anjoy Vision

5MP true full-colour 4G dome camera module

Product functions
1/1.8" CMOS sensor
All-carrier 4G, dual SIM dual standby, adaptive network selection between China Telecom and China Mobile;
Available with 4G or Ethernet port
H.265+ smart encoding reduces bandwidth load
Supports PTZ rotation, home position, patrol, tracking
Supports two-way voice calls for clear communication
Supports Micro SD card (512GB)
APP remote control
Supports human tracking / sound alarm / two-way audio
Smart human detection: area detection, tripwire detection

Specifications
Model	MY-F31H-4G
Image sensor	1/1.8" low-light CMOS
Video processing	H.265+/H.265/H.264 video encoding; bitrate adjustable 0.1M~2Mbps;
Image output	Main stream: 15FPS@(2880×1620, 2560×1440, 2304×1296, 1920×1080, 1280×720); sub stream: 640×360;
Audio interface	1 ch MIC input, 2 ch output: 1 ch amplifier output (8Ω2W), 1 ch active output;
Audio processing	G.711 encoding; two-way voice intercom; audio-video synchronisation;
Network interface	1 × RJ45 Ethernet interface, 10/100M auto-negotiating;
TF interface	1 × TF storage slot, up to 512G;
4G mode	Built-in China Telecom and China Mobile eSIMs, adaptive network selection;
Reset button interface	Supports hardware reset; reset unbinds the device
LED board interface	Integrated LED board driver module (recommended LED board: 12V 500mA full-colour)
Reliability	Full lightning protection for power and network, compliant with national standard GB/T17626.5 and international standard IEC61000-4-5
Functions	OSD, real-time audio and video transmission, human detection, dual-light alarm, sound alarm;
Network protocols	Supports TCP/TP, IPv4, DHCP, RTSP, P2P
Mobile monitoring	Mobile monitoring (iOS, Android); supports AC18Pro
Power supply	DC12V power input
Operating conditions	-20~65℃
