MY-Q12F-CY18
Dual-lens camera module
- Maker:
- Anjoy Vision
- Listed:
- 2025
Anjoy Vision
H.265+ 6MP human detection/smart dual-light/WiFi module
Features
- Product functions
- Dual 1/2.9" 3MP CMOS sensors
- Supports three light modes: dual-light, full-colour, IR
- Single-band WiFi6, 2.4GHz + Bluetooth network provisioning
- Supports 360° PTZ rotation, one-touch home position, one-touch patrol, one-touch tracking, bullet–PTZ linkage
- 18× optical zoom supported
- Available with WiFi or Ethernet port
- H.265+ smart encoding reduces bandwidth load
- Supports two-way voice calls for clear communication
- Supports Micro SD card (512GB) / cloud storage
- APP remote control
- Supports human tracking / dual-light alarm / sound alarm / two-way audio
- Smart human detection: area detection, tripwire detection
| Model | MY-Q12F-CY18 |
|---|---|
| Lens focal length | 5.3±5%~96±5%mm |
| Maximum zoom ratio | 18X |
| Lens iris | F1.8~F3.9 |
| Horizontal range | Horizontal: 360°, vertical: -15~90° |
| Number of presets | 255 |
| Control speed | Horizontal 120°/s, vertical 60°/s |
| Supported functions | Human tracking, preset patrol, area patrol, defog |
| Power-off position memory | Supported |
| Illuminator | IR 700mA per group (2 groups), white light 500mA per group (1 group) |
| Image sensor | 1/2.9" 3MP + 3MP low-light CMOS |
| Video processing | H.265+/H.265/H.264 video encoding; bitrate adjustable 0.1M~1.5Mbps; |
| Image output | Main stream: 2×2304×1296, 1920×1080, 1280×720; sub stream: 640×360; |
| Audio interface | 1 ch MIC input, 2 ch output: 1 ch amplifier output (8Ω2W), 1 ch active output; |
| Audio processing | G.711 encoding; two-way voice intercom; audio-video synchronisation; |
| Network interface | 1 × RJ45 Ethernet interface, 10/100M auto-negotiating; |
| TF interface | 1 × TF storage slot, up to 512G; |
| WiFi | 2.4GHz (WiFi6), WiFi standard IEEE 802.11 b/g/n/ax |
| Bluetooth | Bluetooth 2.1+EDR/3.0/4.x/5.2 |
| Reset button interface | Supports hardware reset; reset unbinds the device |
| LED board interface | Integrated two-channel LED board driver module (recommended LED board: dual-light LED board) |
| Reliability | Full lightning protection for power and network, compliant with national standard GB/T17626.5 and international standard IEC61000-4-5 |
| Functions | OSD, real-time audio and video transmission, human detection, dual-light alarm, sound alarm; |
| Network protocols | Supports TCP/TP, IPv4, DHCP, RTSP, P2P |
| Mobile monitoring | Mobile monitoring (iOS, Android); supports AC18Pro |
| Power supply | DC12V power input |
| Operating conditions | -20~65℃ |
| Dimensions | 58 (L) * 38 (W) + 38 (L) * 38 (W) (excluding lens) |
Files
- MY-Q12F-CY18-pinout-1.jpg (pinout, 2.1 MB)
- MY-Q12F-CY18-pinout-2.jpg (pinout, 1.7 MB)
- MY-Q12F-CY18-spec-sheet.pdf (document, 206 KB)
