CMLFKS16DP
Network Camera
- Maker:
- Longse
- Listed:
- 2025
Longse
16MP Dual Lens Panoramic Network Camera
Features
- High quality imaging with 16MP resolution
- 1/1.8"SONY Starvis2 Back-illuminated CMOS sensor
- Support H.264/H.264+/H.265/H.265+/MJPEG Compression
- 4mm Fixed focal lens
- Housing: Metal & Plastic, IP67
| Series | Dual-lens |
|---|---|
| Image Sensor | 1/1.8" SONY Starvis2 Back-illuminated CMOS sensor |
| Resolution | 16MP |
| Effective Pixels | 3856(H)*2180(V)*2 |
| Compression | H.264/H.264+/H.265/H.265+/MJPEG |
| Audio Compression | G711A/U,AAC,MP2L2 |
| TV System | PAL/NTSC |
| Electronic Shutter Time | Auto: 1/3-1/100000Sec |
| Minimun Illumination | Color: 0.01 Lux@(F1.0, AGC ON), 0 Lux with white light, B/W: 0 Lux with IR |
| S/N Ratio | 60dB |
| Scanning System | Progressive |
| Video Output | Network |
| Reset Button | Support |
| Focal Length & FOV | 4 mm, horizontal FOV 201°, vertical FOV 59° |
| Lens Type | Fixed focal lens, 4 mm |
| Focus Control | Fixed |
| Aperture | F1.0 |
| Pixels | 8MP |
| Supplement Light | IR 4PCS, Warm light 4PCS |
| Supplement Light Distance | IR 50m, Warm light 50m |
| Supplement Light Status | Auto Control |
| Supplement Light Power On | Smart, Manual & Timed mode |
| Ethernet | RJ-45 (10/100Base-T) |
| Wireless | N/A |
| Protocol | TCP/IP, IPv4/v6, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTMP, RTCP, PPPoE, NTP, SMTP, UDP, SNMP, Qos, 802.1x |
| ONVIF | Support ONVIF 24.12(Profile S/T/G/M) |
| P2P | YES |
| POE | Internal, Support IEEE 802.3af |
| Video Delay | 300ms (Within the Lan) |
| Main Stream 1 | 7680*2160@20fps |
| Main Stream 2 | 4096*1152@20fps |
| Main Stream 3 | N/A |
| Sub Stream 1 | 2560*720@20fps |
| Sub Stream 2 | N/A |
| Sub Stream 3 | N/A |
| Tri Stream | N/A |
| IE Brower | Microsoft Edge, IE11, Google Chrome, Firefox, Mac Safari |
| Smart Phone | iPhone, Android |
| Intelligent Analysis | Intrusion Detection/Line Crossing Detection/Enter Area Detection/Leave Area Detection/Line Crossing Count(based on human, vehicle and non-motor vehicle detection), Loitering Detection/People Gathering Detection(based on human detection), Motion Detection(supports the detection based on human, vehicle and non-motor vehicle movement), Illegal Parking(based on vehicle shape and license plates), License Plate Detection, Abandoned Object Detection, Removed Object Detection, Heat Map, Fire Detection, Video Structured Analytics |
| Day/Night | Color/ B&W (IR-CUT ) |
| Image Config | Saturation/Brightness/Contrast/Sharpness, 3D NR, White Balance, Anti Flicker, Video Tampering, HLC, Distortion(Default enable, not configurable), Scene Change Detection |
| Full Color | Support |
| Corridor Pattern | N/A |
| Defog Mode | Support |
| ROI | Support |
| BLC | Support |
| WDR | N/A |
| Motion Detection | Support(support enable the detection based on human movement only) |
| Privacy Masking | 3 Rectangular Zone |
| Recording Mode | NVR/CMS/Web |
| Language | Chinese Simplified, Chinese Traditional, English, Korean, Polish, French, Japanese, Spanish, Portuguese, Italian, Hebrew, Ukrainian,Arabic, Vietnamese, Thai, Hungarian |
| Audio | Default: Built in Mic+Built in Speaker; Option: Audio I/O; Support Sound Detection |
| Alarm | Default: Alarm I/O |
| SD Card Slot | Default: External SD card slot (Max 512GB) |
| RS485 | N/A |
| Housing | Metal+Plastic, IP67 |
| Anti-cut Bracket | NO |
| IR Cut Filter | YES |
| Operation Temperature | -20℃ ~ +50℃ RH95% Max |
| Storage Temperature | -20℃ ~ +50℃ RH95% Max |
| Power Source | DC12V±10%, 950mA |
| Dimension | φ152 x 156.28 mm |
| Weight (N.W./G.W.) | Approx. 1188 g / Approx. 1463 g |
Photos
Files
- CMLFKS16DP-datasheet.pdf (document, 4.7 MB)
