F4M

IP Camera Module

Ruision

1. Support H264, H.265

Main-stream: 4MP(2560*1440)/3MP(2304*1296)/2MP(1920*1080)/1MP(1280*720;

The default stream is 2MP

Sub-stream：448P(800*448)/D1(704*576)/360P(640*360 )/ CIF(352*288)

2. Support dual stream output simultaneously；

3. Support D-WDR, 3D-NR, BLC, Auto-White balance for different environments；

4. Support ONVIF, can connect with other company’s NVR；

5. Support image shutter, can cover the privacy area

6. Support OSD character overlay and network timing

7. Support audio input and output, two-way intercom, audio and video

synchronization；

8. Support a variety types of light board, can support light board with cds or without cds

9. support the human detection function；

10. Support sound and light linkage alarm；

11. Support automatic maintenance function；

12. Support mobile surveillance(iOS, android),Web and VMS；

F4M IP camera module-EN_01.jpg

F4M IP camera module-EN_20240119175413.pdf
