IPG-80X30PSB-WPN
3.0M dual-line network camera module · consumer module
- Maker:
- Xiongmai
- SoC:
- XM535
- Sensor:
- SC3335
- Listed:
- 2020
Xiongmai
3.0M dual-line network camera module
Features
- 3.0M resolution, low illumination clear and fine images
- Support for wired and wireless connections
- Supporting human detection
- Support 2D/3D noise reduction,digital wide dynamic
- AdvancedH.265X video compression,Super low rate,high definition quality of image
- Professional anti-lightning,conform to GB/T17626.5 and IEC61000-4-5
- Support mobile phone monitoring(iOS, Android)
- Provide web、CMS、provide SDK development
- Support cloud technology,easy to achieve network penetration,fro in-line and alarm information pushed
| Model | IPG-80X30PSB-WPN |
|---|---|
| System structure | Embedded RTOS, dual-core 32-bit DSP (XM535),pure hard compression ,watch dog |
| Sensor | 3.0M 1/2.8"SC3335 High performance CMOS sensor ,color 0.001Lux@F1.2,black/white 0.0001Lux@F1.2 |
| Video compression | H.265X coding,support dual stream,AVI;0.1M~8Mpbs variable |
| Image output | Main stream: 2288*1288@12fps; sub-stream: 640*360@12fps |
| Shutter | 1/50(1/60)s to 1/10,000s |
| Lens | N/A |
| Day and night | Support IR-CUT |
| Noise reduction | Support 2D/3D |
| Wide dynamic | Support digital |
| Auto iris | N/A |
| Audio compression | G.711 standard compression,support two-way Bidrectional Talk,support for audio and video synchronization |
| Audio interface | 1ch input,level:2Vp-p,impedance:1kΩ,support sound pick-up input;1ch output,impedance:16Ω,30mw,support microphone; |
| Network interface | 1*RJ45 10/100M adaptive Ethernet port(Merge with power interface) |
| Extension interface | N/A |
| Singal interface | One photo resistance interface,one IR-CUT interface ,support photo resistance signal and IR-CUT links to IR |
| PTZ interface | N/A |
| Alarm I/O | N/A |
| Wireless interface | Supports wireless connections |
| Reset interface | Support |
| Storage mode | Local TF card storage, up to 128G; cloud storage |
| Reliability | Comprehensive lightning protection, 7 * 24 hours 65 ℃ high temperature stable and reliable testing |
| Intelligence analysis | Supporting human detection and customizing other intelligent functions |
| Other function | It supports remote monitoring of mobile client, push message after alarm of human figure detection, and supports MJPEG capture |
| ONVIF | Support |
| Mobile monitoring | Support multiple mobile monitoring（iOS，Android） |
| Power | DC12V |
| Dimension | 38mm*38mm+38mm*38mm |
| Other | N/A |
Photos
Files
- IPG-80X30PSB-WPN-pinout-1.png (pinout, 191 KB)
- IPG-80X30PSB-WPN-pinout-2.png (pinout, 102 KB)
- IPG-80X30PSB-WPN-pinout-3.png (pinout, 125 KB)
- IPG-80X30PSB-WPN-interface-en.pdf (document, 442 KB)
- IPG-80X30PSB-WPN-interface-zh.pdf (document, 531 KB)
