IPG-80X50PSB-WPN

5.0M dual-line network camera module · consumer module

Maker:
Xiongmai
SoC:
XM550
Sensor:
SC5335P
Listed:
2020

Xiongmai

5.0M dual-line network camera module

Features

  • 5.0M resolution, clear and fine images
  • Support for wired and wireless connections
  • Support 2D/3D noise reduction,digital wide dynamic
  • Advanced H.265X video compression,Super low rate,high definition quality of image
  • Professional anti-lightning,conform to GB/T17626.5 and IEC61000-4-5
  • Support mobile phone monitoring(iOS, Android)
  • Support cloud technology,easy to achieve network penetration,fro in-line and alarm information pushed
Specifications
ModelIPG-80X50PSB-WPN
System structureEmbedded RTOS, dual-core 32-bit DSP (XM550),pure hard compression ,watch dog
Sensor5.0M 1/2.7"SC5335P low illumination CMOS sensor ,color 0.001Lux@F1.2,black/white 0.0001Lux@F1.2
Video compressionH.265X coding,support dual stream,AVI;0.1M~8Mpbs variable
Image outputMain stream: 2592*1944@12fps; sub-stream: 640*360@12fps
Shutter1/50(1/60)s to 1/10,000s
LensNo
Day and nightSupport IR-CUT
Noise reductionSupport 2D/3D
Wide dynamicSupport digital
Auto irisN/A
Audio compressionG.711 standard compression,support two-way Bidrectional Talk,support for audio and video synchronization
Audio interface1ch input,level:2Vp-p,impedance:1kΩ,support sound pick-up input;1ch output,impedance:16Ω,30mw,support microphone;
Network interface1*RJ45 10/100M adaptive Ethernet port
Extension interfaceN/A
Singal interfaceOne photo resistance interface,one IR-CUT interface ,support photo resistance signal and IR-CUT links to IR
PTZ interfaceN/A
Alarm I/ON/A
Wireless interfaceSupports wireless connections
Reset interfaceSupport
Storage modeLocal TF card storage, up to 128G; cloud storage
ReliabilityComprehensive lightning protection, 7 * 24 hours 65 ℃ high temperature stable and reliable testing
Intelligence analysisSupporting human detection and customizing other intelligent functions
Other functionIt supports remote monitoring of mobile client, push message after alarm of human figure detection, and supports MJPEG capture
ONVIFSupport
Mobile monitoringSupport multiple mobile monitoring（iOS，Android）
PowerDC12V
Dimension38mm*38mm+38mm*38mm
OtherN/A

Photos

  • front of IPG-80X50PSB-WPN
