IPM-50HV20PE-WR
2.0M Robot Dedicated Module（WR） · consumer module
- Maker:
- Xiongmai
- SoC:
- HI3518EV200
- Listed:
- 2017
Xiongmai
2.0M Robot Dedicated Module（WR）
Features
- Supports Wireline、Wi-Fi, a key WPS function
- Support Micro SD card,up to 32G
- Support 3D DNR, DWDR
- Support for mobile video surveillance(iOS,android)
- Support Web, CMS, platform management software MYEYE,Provide SDK
- Support cloud service, network penetration, alarm information pushed to phone ,etc.
| Model | IPM-50HV20PE-WR |
|---|---|
| System structure | Embedded RTOS, dual-core 32-bit DSP (Hi3518EV200),pure hard compression ,watch dog |
| sensor | Match and use with ISM-5020PS-R,color 0.1Lux@F1.2,black/white 0.01Lux@F1.2 |
| Video compression | H.264,support dual stream,AVI;0.1M~8Mpbs variable;1~30f/s variable |
| Image output | Main stream: 1920*1080@15fps，1280*720；sub-stream: 704*576; |
| Network interface | 1 RJ45, 10/100M Ethernet adaptive interface; support RTSP / FTP / PPPOE / DHCP / DDNS / NTP / UPnP network protocols; |
| Network connection | Supports Wireline、Wi-Fi, a key WPS function; |
| Hardware features | Support a key reset function |
| Audio interface | 1ch input,electrical level 2Vp-p,impedance 1kΩ,support pickup input;1ch output, impedance 16Ω,30mv output power,support to connect the headset or power amplifier |
| Audio processing | G.711 standard compression,support two-way Bidrectional Talk,support for audio and video synchronization |
| Alarm input | 1 channel (Self welding Phoenix terminal) |
| Alarm output | 1 channel (Self welding Phoenix terminal) |
| Motor interface | A horizontal motor interface, a vertical electrical interfaces, a limit switch; |
| Micro SD card | Support,maximum 32G |
| Lightning Protection | Power lightning protection,in line with national standards GB/T17626.5,the international standard IEC61000-4-5. |
| Other function | Support WEB configure,support for OSD,support real-time video transmission, support mobile surveillance,support for mobile detection alarm center after the screen pop-up reminders and linkage;supports JPEG capture;support unified client remote monitoring software,MYEYE platform system applications;provide perfect the SDK development package; |
| ONVIF | Unsupport |
| Mobile monitoring | Support multiple mobile monitoring（iOS，Android） |
| Power | DC5V |
| Other | Restore factory settings button interface, support photo resistor linkage; |
| Explain | Does not accept any custom. |
Photos
Files
- IPM-50HV20PE-WR-pinout-1.png (pinout, 154 KB)
- IPM-50HV20PE-WR-pinout-2.png (pinout, 104 KB)
- IPM-50HV20PE-WR-datasheet.docx (document, 68 KB)
- IPM-50HV20PE-WR-datasheet.pdf (document, 174 KB)
