JF-SD-MN4640R-X1D2-4GSV
AOV Camera
- Maker:
- Xiongmai
- Listed:
- 2025
JFTech
4MP AOV AI-ISP Battery 4G Bullet&PT Camera
JF-SD-MN4640R-X1D2-4GSV is a 4MP 4-inch battery 4G Bullet&PT Camera, with built-in battery power, low power consumption and ultra-long standby(1fps recording(AOV)+12fps recording(Wake-up status)), 4G network connection, full-color night vision, support solar charging. It is suitable for indoor and outdoor scenarios such as villages, aquaculture, forestry, agriculture, factories, rivers, warehouses, industrial parks, and power facilities.
| Image Sensor | 2*1/2.9" Low illumination Sensor |
|---|---|
| Min. Illumination | Color:0.01Lux |
| Shutter Speed | 1/50(1/60)s to 1/10,000s |
| Lens | 4mm,6mm,M12 |
| Mic | Built-in microphone |
| Speaker | Built-in speaker |
| Day & Night | full-color night vision |
| Video storage | TF card storage, cloud storage |
| Voice talk | Two-way voice talk |
| Video Coding | H.265AI |
| Output Bit Rate | 0.1Mbps~8Mbps |
| Audio Coding | G.711a |
| Frequency band | LTE-FDD：B1/B3/B5/B8 LTE-TDD：B34/B38/B39/B40/B41 |
| Rate | upstream up to 2Mbps, downstream up to 6Mbps |
| Max.Resolution | 1920*2160 |
| Frame Rate | 12FPS |
| Storage Interface | 1*TF Card interface (max. 128G) |
| SIM card slot | 1*SIM card, Slot support SIM card replacement |
| Button | 1*Reset Button |
| Button | 1*switch button |
| Power Interface | 1*Type-C interface |
| Temperature | -10℃-＋60℃ |
| Humidity | 10%-95% RH |
| Power Supply | Built-in 10400mah lithium battery |
| Solar panels | 5V/7W Type-C，232.2mm*166.6mm |
| Vision Distance | Visible: 20m |
| Pickup Distance | ≥5 m |
| Waterproof | IP66 |
| Bare Weight | About 700g |
| Installation | Wall-mounted, top-mounted |
| Dimensions | About 207.7mm*292.2mm*152.7mm |
Photos
Files
- Parameters-for-JF-SD-MN4640R-X1D2-4GSV.pdf (document, 347 KB)
