JZC-80X50PSB-RG

5MP wired and wireless network HD mini PTZ module · IP Camera Module

Maker:
Xiongmai
SoC:
XM550
Sensor:
SC5335P
Listed:
2020

Xiongmai

5MP wired and wireless network HD mini PTZ module

Features

  • 5MP resolution,clear and fine images
  • Support for wired and wireless connections
  • Support 2D/3D noise reduction,digital wide dynamic
  • Advanced H.265X video compression,Super low rate,high definition quality of image
  • Professional anti-lightning,conform to GB/T17626.5 and IEC61000-4-5
  • Support ONVIF;access third party
  • Supporting human detection ,support to customize intelligent functions
  • Support various mobile monitoring(iPhone,Android)
  • Support cloud technology,easy to achieve network penetration,fro in-line and alarm information pushed
Specifications
ModelJZC-80X50PSB-RG
System structureEmbedded RTOS, dual-core 32-bit DSP ,pure hard compression ,watch dog
Sensor5MP 1/2.7"SC5335P CMOS sensor,color 0.001Lux@F1.2,black/white 0.0001Lux@F1.2
Video compressionH.265X coding,support dual stream,AVI;0.1M~8Mpbs variable
Image outputMain stream: 2592*1944@12fps; sub-stream: 640*360@12fps
Shutter1/50(1/60)s to 1/10,000s
LensNo
Day and nightSupport IR-CUT
Noise reductionSupport 2D/3D
Wide dynamicSupport digital
Auto irisN/A
Audio compressionG.711 standard compression,support two-way Bidrectional Talk,support for audio and video synchronization
Audio interface1ch input,level:2Vp-p,impedance:1kΩ,support sound pick-up input;1ch output,impedance:16Ω,30mw,support microphone;
Network interface1*RJ45 10/100M adaptive Ethernet port
Extension interfaceN/A
Singal interfaceOne photo resistance interface,one IR-CUT interface ,support photo resistance signal and IR-CUT links to IR
PTZ interfaceOne horizontal motor interface，one vertical electrical interface
Alarm I/ON/A
Wireless interfacesupporting wireless network connection
Reset interfaceSupport
Storage modeLocal TF card storage, up to 128G; cloud storage
ReliabilityComprehensive lightning protection, 7 * 24 hours 65 ℃ high temperature stable and reliable testing
Intelligence analysisSupporting human detection and customizing other intelligent functions
Other functionIt supports remote monitoring of mobile client, push message after alarm of human figure detection, and supports MJPEG capture
ONVIFSupport
Mobile monitoringSupport multiple mobile monitoring（iOS，Android）
PowerDC5V-12V
Dimension38mm*78mm+38mm*38mm+24mm*38mm
OtherDoes not accept any custom.

Photos

  • front of JZC-80X50PSB-RG
