LPG-DG1

1.0M Low power doorbell wireless HD IP module · Battery Camera Module

Xiongmai

1.0M Low power doorbell wireless HD IP module

1.0M resolution, clear and fine images
PIR infrared human sensor to support passive infrared sensing
The standard is equipped with 24V AC charging module and doorbell pressing module
Support 2D/3D noise reduction, digital wide dynamic
Advanced H.265X video compression, Super low rate ,high definition quality of image
Professional anti-lightning, conform to GB/T17626.5 and IEC61000-4-5。
Support mobile phone monitoring(iOS, Android)
Support cloud technology ,easy to achieve network penetration, fro in-line and alarm information pushed

Specifications
Model	LPG-DG1
System structure	Embedded RTOS, dual-core 32-bit DSP (Hi3518EV201),pure hard compression ,watch dog
Sensor	1.0M 1/4 "SC2145H CMOS sensors; Color 0.1 Lux@F1 .2, black and white 0.01 Lux@F1 .2
Video compression	H.265X/H.264,support dual stream,AVI;0.1M~8Mpbs variable
Image output	Main stream: 1280720，sub-stream: 704576;
Shutter	1/50(1/60)s to 1/10,000s
Lens	No
Day and night	Support IR-CUT
Noise reduction	Support 2D/3D
Wide dynamic	Support digital
Auto iris	N/A
Audio compression	G.711,support bidrectional talk,audio&video synchronization
Audio interface	1ch input,level:2Vp-p,impedance:1kΩ,support sound pick-up input;1ch output,impedance:16Ω,30mw,support microphone
Network interface	N/A
Extension interface	N/A
Singal interface	One photo resistance interface,one IR-CUT interface ,support photo resistance signal and IR-CUT links to IR
PIR	Support
Motor interface	N/A
Alarm I/O	N/A
WIFI interface	Support wireless connections
Reset interface	Support
SD Card	Support
Reliability	Comprehensive lightning protection, 7 * 24 hours-10℃～65℃ high temperature stable and reliable testing
Intelligence analysis	NO
Other function	Support for smart alarms; Support APP remote monitoring software; Full SDK development package
ONVIF	NO
Mobile monitoring	Support multiple mobile monitoring（iOS，Android）
Power	Power(optional):DC5V, DC24V,2*18650
Dimension	Low Power Doorbell
Other	N/A
