LPG-QG2-4GSEU

1080P 4G Solar Dome Camera module · consumer module

Maker:
Xiongmai
Sensor:
IMX307
Listed:
2021

Xiongmai

1080P 4G Solar Dome Camera module

Features

  • 1080p resolution, clear and delicate image
  • Support PIR human infrared sensing and microwave dual detection
  • Support app remote wake-up
  • DC5V power supply ；Support solar power supply duration (need external solar power panel)
  • Support European 4G network connection
  • Support 2D/3D noise reduction,digital wide dynamic
  • Advanced H.265X video compression,Super low rate,high definition quality of image
  • Professional anti-lightning,conform to GB/T17626.5 and IEC61000-4-5。
  • Support mobile phone monitoring(iOS, Android)
  • Support cloud technology,easy to achieve network penetration,fro in-line and alarm information pushed
Specifications
ModelLPG-QG2-4GSEU
System structuredual-core 32-bit DSP（XM650）, pure hard compression ,watch dog
Sensor2MP 1/2.8"IMX307 CMOS sensor
Min. illuminationColor：0.0001Lux @(F1.2,AGC ON); 0 Lux with IR; Black/White: 0.00001 Lux @ (F1.2,AGC ON),0 Lux with IR
Video compressionH.265Xcoding,support dual stream,AVI;0.1M~8Mpbs variable
Image outputMain stream: 1920*1080@12fps; sub-stream: 640*360@12fps
Shutter1/50(1/60)s to 1/10,000s
LensN/A
Day and nightSupport IR-CUT
Noise reductionSupport 2D/3D
Wide dynamicSupport digital
Auto irisN/A
Audio compressionG.711 standard compression,support two-way Bidrectional Talk,support for audio and video synchronization
Audio interface1ch input,level:2Vp-p,impedance:1kΩ,support sound pick-up input;1ch output,impedance:16Ω,30mw,support microphone;
Network interfaceN/A
Extension interfaceN/A
Singal interfaceone IR-CUT interface
PTZ interfaceOne horizontal motor interface, one vertical electrical interface
Alarm I/ON/A
Wireless interfaceSupport European 4G network connection
Reset interfaceSupport
Storage modeLocal TF card storage, up to 128G; cloud storage
ReliabilityComprehensive lightning protection, 7 * 24 hours 65 ℃ high temperature stable and reliable testing
Intelligence analysisSupport PIR human infrared sensing and microwave dual detection and customizing other intelligent functions
Other functionSupport cloud technology,easy to achieve network penetration,fro in-line and alarm information pushed
ONVIFN/A
Mobile monitoringSupport multiple mobile monitoring（iOS，Android）
PowerDC5V±10%
Dimension59mm*50mm+38mm*38mm

Photos

  • front of LPG-QG2-4GSEU
