NBD8008R-PL

8ch 1080P H.265 NVR Board · NVR Board

Xiongmai

8ch 1080P H.265 NVR Board

Support HDMI 1080P output VGA HD output
Support ONVIF;access third party
Support web, CMS, center platform management software MYEYE, provide SDK development
Support multiple cloud technology, network penetration, alarm information pushed to your phone and other functions
Support multiple network services (support DHCP, FTP, DNS, DDNS, NTP, UPNP, EMAIL, IP searches, Alarm Center, etc.)

Specifications
Model	NBD8008R-PL
System	Main processor / Hi3536D
Operating System	Embedded Linux
System resources	Simultaneous multi-channel real-time recording, playback, network operation, USB backup
Interface	Operator interface / 16-bit true color graphic menu operation interface, support mouse operation
Preview	1/4/8
Video	Video input (IP) / 45M /84M
Access bandwidth	64Mbps
Forwarding bandwidth	36Mbps
Video compression	H.265++/H.265+/H.265/H.264
Display quality	Max:1920*1080
Playback quality	1080P
Decode	15M /14M
VR	unsupport
Motion detection	Support(depend on camera)
Audio	Audio compression / G.711A
Intercom	unsupport
record &play back	Recording mode / Manual>Alarm>Dynamic Detection>Timing
Local payback	15M /14M
Search mode	Search by Time/Calendar/Event/Channel
Record storage	HDD、Network
Backup mode	Network backup, USB hard disk, USB burner, SATA burner
External interface	Video output / 1ch VGA，1ch HDMI HD output
Audio I/O	0/1
Alarm I/O	0/0
Network interface	1*RJ45 10M/100M Adaptive Ethernet port
USB interface	2*USB2.0 ports
HDD	1 SATA(Up to 8TB for each disk)
ESATA	No
Serial interface	No
Other	ONVIF / Support
Power supply	12V/2A
Power Consumption	<10W(Without HDD)
Work environment	Temperature:0℃-＋55℃ , Humidity:10%－90%RH , Atm:86kpa－106kp
Dimension	137mm*82mm
Weight	A total of about 92g
