XAG-50X10PK-M
1.0M(720P) AHD/TVI/CVI Hybrid Module · XVI&AHD Hybrid Camera Module
- Maker:
- Xiongmai
- Listed:
- 2018
Xiongmai
1.0M(720P) AHD/TVI/CVI Hybrid Module
Features
- 720P high resolution, the image is more clear and delicate
- Zero-latency data transmission, full real-time, high fidelity
- Long transmission distance, coaxial transmission up to 500 meters
- Support coaxial upgrade, version upgrade convenient and efficient
- Compatible with AHD/TVI/CVI backend
- Support XVI，image quality is better
- NTSC&PAL 2 in 1, easy to switch through back-end
- High-definition quality products with competitive price.
| Specifications | XAG-50X10PK-M |
|---|---|
| ISP | XM310V300 |
| Sensor | 1/4 inch SP140A sensor |
| Signal format | AHD/TVI/CVI |
| Video Resolution | PAL/NTSC : 1280*720 |
| Minimum Illumination | Color：0.1Lux@（F1.2，AGC ON），0Lux with IR / Black & White：0.01Lux@（F1.2，AGC ON），0Lux with IR |
| Photosensitive Resistance | 1 photosensitive resistance interface, support the photosensitive resistor input signal and image, IR-CUT, infrared lamp linkage |
| Shutter | 1/50(1/60) seconds to 1/10,000 seconds |
| Day and Night Function | Support IR-CUT |
| Lens Parameters | C/CS interface, M12 lens optional |
| Video output | 720P@25fps |
| Power | DC12V±10% |
| Temperature and Humidity | - 10 ℃ ~ 60 ℃, humidity is less than 90% (no condensation) / Consumption |
| Size | Standard 32*32 positioning hole, compatible with 38*38 hole |
| Remarks | Support coaxial upgrade |
Photos
Files
- XAG-50X10PK-M-pinout-1.png (pinout, 203 KB)
- XAG-50X10PK-M-interface-zh.doc (document, 10.9 MB)
- XAG-50X10PK-M-interface-zh.pdf (document, 274 KB)
- XAG-50X10PK-M-parameters.pdf (document, 1.4 MB)
