XAG-53X50PSB-U
5MP XVI/AHD/TVI/CVI/CVBS Hybrid Module · XVI&AHD Hybrid Camera Module
- Maker:
- Xiongmai
- Sensor:
- SC5335P
- Listed:
- 2021
Xiongmai
5MP XVI/AHD/TVI/CVI/CVBS Hybrid Module
Features
- 5MP FHD resolution, the image is more clear and delicate
- Zero-latency data transmission, full real-time, high fidelity
- Long transmission distance, coaxial transmission up to 500 meters
- Support UTC, enable OSD by the back-end
- Support coaxial upgrade, version upgrade convenient and efficient
- Support XVI, image quality is better
- Support XVI/AHD/TVI/CVI/CVBS DVR
- NTSC&PAL 2 in 1, easy to switch through back-end
- High-definition quality products with competitive price.
| Specifications | XAG-53X50PSB-U |
|---|---|
| ISP | XM350V200 |
| Sensor | 1/2.7 inch SC5335P sensor |
| Signal format | XVI/AHD/TVI/CVI/CVBS |
| Video Resolution | PAL/NTSC : 2560*1920 |
| Minimum Illumination | Color：0.01Lux@（F1.2，AGC ON），0Lux with IR / Black & White：0.001Lux@（F1.2，AGC ON），0Lux with IR |
| Alarm Interface | can be connected with Passive Infrared Detection devices(PIR) |
| Photosensitive Resistance | 1 photosensitive resistance interface, support the photosensitive resistor input signal and image, IR-CUT, infrared lamp linkage |
| Shutter | 1/50(1/60) seconds to 1/10,000 seconds |
| Day and Night Function | Support IR-CUT |
| Lens Parameters | C/CS interface, M12 lens optional |
| Video output | XVI/AHD/TVI/CVI:5MP@20fps 5MP@12.5fps；CVBS:960H P/N |
| Power | DC12V±10% |
| Temperature and Humidity | - 10 ℃ ~ 60 ℃, humidity is less than 90% (no condensation) / Consumption |
| Size | Standard 32*32 positioning hole |
| Remarks | Support UTC,coaxial upgrade |
Photos
Files
- XAG-53X50PSB-U-pinout-1.png (pinout, 334 KB)
- XAG-53X50PSB-U-interface-en.pdf (document, 1.3 MB)
- XAG-53X50PSB-U-interface-zh.pdf (document, 1.3 MB)
- XAG-53X50PSB-U-parameters.pdf (document, 1.4 MB)
